Description
Features and Benefits
· Integral 7 day programmable timer
· Programmable filter change indicator
· Electronic temperature control, programmable between 80°C - 98°C
· Comprehensive diagnostics system
Installation
As per instructions supplied
Plumbing
Designed for direct connection to a potable cold water supply using the fittings supplied. An isolating valve should be installed between the supply and the heater. These wall mounted boilers have a choice of connection through rear or from beneath and require 2 bar incoming water pressure.
Electrical
To be connected to 230 volt 13 amp or 30 amp (6kW) supply.
Construction
Stainless steel or impact resistant thermoplastic case.
Stainless steel heating chamber.
Low voltage switching.
2 safety cut-outs.
Approvals
WRAS approved.
Specification
Dimension: Height 414 Width 314 Depth 215 (mm)
Tap Depth: 90 (mm)
Power loading: 3 (kW)
Heat-up time: 11 minutes
Recovery Rate: 0.5 (Litres)
Rapid Draw-Off: 3 (Litres)
Rapid Draw-Off: 18 (Cups)
Rapid Draw-Off: 168 (Cups)
Hourly Output: 28 (Litres)
Stand by Loss: 0.1 (kW/h)
* Based on 6 Cups Per Litre
